纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-010[02]) - AIR CLEANER ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
690 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | YN11P01110P1 | [1] | AIR INTAKE TUBE,100 mm OD | KOB |
| 3. | YN11P01122P1 | [1] | INTAKE AIR HOSE | KOB Superseded by part number: 87530994 |
| 4. | YN11P01109P1 | [1] | INTAKE AIR HOSE | KOB Superseded by part number: 87530995 |
| 6. | ZC16X11000 | [3] | CLIP | KOB |
| 7. | ZS18C10025 | [12] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 8. | YN11P01074P1 | [1] | BRACKET | KOB |
| 9. | YN11P01075D3 | [1] | HOSE | KOB Superseded by part number: 87530996 |
| 10. | ZC16X02800 | [2] | CLIP | KOB |
| 11. | ZC46X29011 | [1] | CLIP | KOB |
| 12. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 13. | ZS18C08020 | [1] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 16. | ZW16P10000 | [12] | WASHER | KOBID 10.5 x OD 21 x Th 2.0mm |
| 17. | ZW16P08000 | [3] | WASHER | KOBID 8 x OD 17 x Th 1.6mm |
