纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-016[00]) - SWING MOTOR - INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
625 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ZS13C20055 | [13] | SCREW | KOBScrew -- M20x2.50x55mm |
| 2. | YN64H01391D1 | [2] | CAP | KOB10.0mm Slotted Plastic |
| 3. | YN32W01101D1 | [1] | LEVEL GAUGE | SM385.5mm Long (15-11/64 in) |
| 4. | YN32W01114D1 | [1] | RIGID TUBE | SM262mm Long (10-5/16 in) |
| 5. | YN32W01122D1 | [1] | RIGID TUBE | SM |
| 6. | ZE91T12000 | [1] | PLUG | SMCap, 3/4" PT |
| 7. | YN15V00036F3 | [1] | MOTOR,129.2CC | KOBSwing Hydraulic Motor Assembly Superseded by part number: YN15V00069F1 |
| 7-1. | YN15V00035F1 | [1] | HYDRAULIC MOTOR | SMAssembly - See Fig. 07-001[01] |
| 7-2. | YN32W00022F2 | [1] | GEAR REDUCTION UNIT | KOBSwing Gear Reduction Unit - See Fig. 07-002[00] |
