| 1. | YN30H01208P1 | [1] | ELBOW | SM |
| 2. | ZS28C12030 | [4] | SCREW,Hex Socket Head, M12 x 30mm | KOBScrew -- M12x1.75x30mm |
| 3. | ZW26K12000 | [4] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 4. | 45Z91D104 | [1] | O-RING,3.53mm Thk x 69.44mm ID, 80 Duro | KOBID 69.44 ± 0.38 OD 76.50mm Superseded by part number: 923582 |
| 5. | YN30H01079D3 | [1] | HOSE | KOB |
| 6. | ZX25M12200 | [1] | HOSE,9.53mm ID x 2200mm L | KOB |
| 7. | YN30HU1006P1 | [1] | FLANGE | KOB |
| 8. | 2444R399D3 | [1] | ELBOW | KOB90° -- 3/4"PFx1/2"PFx35.5mm Long (Incls. O-Ring ZD12P01800) |
| . . | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 9. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 10. | 2444R402D9 | [1] | HYD CONNECTOR | KOB |
| 11. | ZE12X20000 | [2] | CLAMP | KOBHALF |
| 12. | EW02E01015DA | [2] | CLIP | KOBClamp -- Ø30x30mm Long |
| 13. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
| 14. | HM83C10035G1 | [4] | BOLT | KOBM10x35mm |
| 15. | ZS28C10045 | [4] | SCREW,Hex Socket Head, M10 x 45mm | KOBM10x1.50x45mm |
| 16. | ZW26K10000 | [4] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm |
| 17. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 18. | ZD12P03800 | [1] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 19. | ZS28C10030 | [2] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm |
| 20. | ZW16P10000 | [2] | WASHER | KOBID 10.5 x OD 21 x Th 2.0mm |
| 21. | ZH32X12000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| . . | 237-6012 | [1] | O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro | CASSAE No. 12-1, Not Shown Superseded by part number: 72186120, 167266, 79051113 |
| 22. | 2414Z199D90 | [1] | TUBE | KOB |
| 23. | 2420Z2185 | [1] | GROMMET | KOB |
| 24. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
