纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-021[01]) - HYD LINES, UPPER (STD) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
470 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YN03H01805D1 | [1] | HYDRAULIC HOSE | KOB1500mm Long (59-1/16 in) |
| A2. | YN03H01886D1 | [1] | HYDRAULIC HOSE | KOB1460mm Long (57-31/64 in) |
| A3. | YN03H01886D2 | [1] | HYDRAULIC HOSE | KOB1450mm Long (57-3/32 in) |
| A4. | YN03H01886D3 | [1] | HYDRAULIC HOSE | KOB650mm Long (25-1/2 in) |
| A5. | YN03H01886D4 | [1] | HOSE | KOB1390mm Long (54-23/32 in) |
| A6. | YN03H01886D5 | [1] | HYDRAULIC HOSE | KOB1440mm Long (56-11/16 in) |
| A7. | YN03H01887D1 | [1] | HYDRAULIC HOSE | KOB500mm Long (19-11/16 in) |
| A8. | YN03H01887D2 | [1] | HYDRAULIC HOSE | KOB1190mm Long (46-55/64 in) |
| A9. | YN03H01887D3 | [1] | HYDRAULIC HOSE | KOB1220mm Long (48-1/32 in) |
| A10. | YN03H01889D1 | [1] | HOSE | KOB1650mm Long (64-31/32 in) |
| A17. | ZG23F12012 | [2] | HYD CONNECTOR | KOB1 3/16" 12UN-3/4" PT x 48mm Long (Incls. O-Ring ZD12P02400) |
| A17-1. | ZD12P02400 | [1] | O-RING | KOB(Part of ZG23F12012), ID 23.70 ± 0.24 x OD 30mm |
| A25. | ZD12A01800 | [2] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
