| A1. | YN03H01805D1 | [1] | HYDRAULIC HOSE | KOB1500mm Long (59-1/16 in) |
| A2. | YN03H01886D1 | [1] | HYDRAULIC HOSE | KOB1460mm Long (57-31/64 in) |
| A3. | YN03H01886D2 | [1] | HYDRAULIC HOSE | KOB1450mm Long (57-3/32 in) |
| A4. | YN03H01886D3 | [1] | HYDRAULIC HOSE | KOB650mm Long (25-1/2 in) |
| A5. | YN03H01886D4 | [1] | HOSE | KOB1390mm Long (54-23/32 in) |
| A6. | YN03H01886D5 | [1] | HYDRAULIC HOSE | KOB1440mm Long (56-11/16 in) |
| A7. | YN03H01887D1 | [1] | HYDRAULIC HOSE | KOB500mm Long (19-11/16 in) |
| A8. | YN03H01887D2 | [1] | HYDRAULIC HOSE | KOB1190mm Long (46-55/64 in) |
| A9. | YN03H01887D3 | [1] | HYDRAULIC HOSE | KOB1220mm Long (48-1/32 in) |
| A10. | YN03H01889D1 | [1] | HOSE | KOB1650mm Long (64-31/32 in) |
| A11. | YN03H01851P1 | [1] | TUBE | KOBTUBE |
| A12. | YN03H01852P1 | [1] | TUBE | KOBTUBE |
| A13. | YN03H01854P1 | [1] | SUPPORT | KOBSUPPORT |
| A14. | YN03H01840P1 | [1] | CLAMP | KOBCLAMP |
| A15. | YN03H01427P1 | [2] | CLAMP | KOB122.5x50x48mm |
| A16. | YN03H01432P1 | [4] | BUSHING,28mm ID x 56mm OD x 70mm L | KOBSplit -- ID 28 x OD 38 x 70mm Long |
| A18. | ZE12X16000 | [20] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| A19. | HM83C10035G1 | [48] | BOLT | KOBM10x35mm |
| A20. | ZM73C12035 | [2] | BOLT,M12x35mm - Course Thread | KOBM12x1.75x35mm (Incls. Washer) |
| A21. | ZS18C10075 | [2] | SCREW,Hex, M10 x 75mm | KOBM10x1.50x75mm |
| A22. | ZS18C10060 | [4] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| A23. | ZW16H10000 | [6] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| A24. | ZD12A01600 | [2] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| A26. | ZD12A02100 | [2] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
| A27. | ZD12P03400 | [12] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| B1. | YN03H01884P1 | [1] | PLUG | SM(Incls. O-Ring ZD12P04800) |
| B2. | ZE12Q16000 | [2] | PLUG | KOB(Incls. O-Ring ZD12P03400) |
| B3. | ZE72X06000 | [2] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| B4. | HM83C10030G1 | [8] | BOLT | KOBM10x30mm |
| B5. | ZM73C12030 | [2] | BOLT,M12x30mm - Course Thread | KOBM12x1.75x30mm (Incls. Washer) |
| B6. | ZD12P04800 | [1] | O-RING,3.5mm Thk x 47.7mm ID | KOBID 47.70 ± 0.44 x OD 54.7mm |
