纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-022[00]) - HYD LINES, UPPER (NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
558 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN03H01806D1 | [1] | HYDRAULIC HOSE | KOB1370mm Long (53-15/16 in) |
| 2. | YN03H01807D1 | [1] | HYDRAULIC HOSE | KOB1480mm Long (58-17/64 in) |
| 3. | LQ03H01282D1 | [1] | HOSE,38.1mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 4. | ZE12Q16000 | [1] | PLUG | KOB(Incls. O-Ring ZD12P03400) |
| 5. | ZE12X16000 | [2] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| 6. | ZE13X20001 | [4] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) Superseded by part number: ZE13X20000 |
| 7. | ZS18C14045 | [4] | CAP,Hex, M14 x 45mm | KOBScrew -- M14x2.0x45mm |
| 8. | ZS18C14050 | [4] | SCREW,Hex, M14 x 50mm | KOBM14x2.0x50mm |
| 9. | HM83C10030G1 | [4] | BOLT | KOBM10x30mm |
| 10. | HM83C10035G1 | [4] | BOLT | KOBM10x35mm |
| 11. | HM83C12035G1 | [4] | BOLT | KOBM12x35mm |
| 12. | ZW26X14000 | [8] | WASHER | KOBID 14 x OD 24.5 x Th 3.5mm |
| 13. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 14. | ZD12P03800 | [2] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 15. | ZD12P04800 | [2] | O-RING,3.5mm Thk x 47.7mm ID | KOBID 47.70 ± 0.44 x OD 54.7mm |
