纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-023[00]) - HYD LINES, UPPER (ROTATION) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1005 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN03HU1019P1 | [1] | TUBE | KOBTUBE |
| 2. | YN03HU1020P1 | [1] | TUBE | KOBTUBE |
| 3. | YN03HU1021P1 | [1] | SUPPORT | KOBSUPPORT |
| 4. | ZC27X28012 | [2] | CLAMP | KOB Superseded by part number: YN43H01097P1 |
| 5. | 2444T2958 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 6. | ZA38F22008 | [2] | HYD CONNECTOR | SMElbow, 90° -- 1/2" PF - M30x1.50x45mm Long (No O-Ring supplied) |
| 7. | ZM73C12025 | [2] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
| 8. | ZS18C10060 | [2] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 9. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 10. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 11. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 12. | EW02E01015D9 | [1] | CLIP,20mm ID, P Type | KOBClamp -- Ø20x25mm Long |
| 13. | ZM73C10025 | [1] | BOLT,M10x25mm - Course Thread | KOBM10x1.50x25mm (Incls. Washer) |
| . . | 2444Z2870D1 | [2] | HYD CONNECTOR | KOBNot Shown, Part Of 6 and 11 |
