纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-024[00]) - HYD LINES, SWIVEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
230 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | HH25X08008G5 | [1] | ELEC CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 1-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 2. | ZG33F12012 | [3] | 90 ELBOW,1 3/16"-12 UN x PF 3/4" | KOB90° -- 1-3/16" -12UN x 3/4" PF (Incls. O-Ring ZD12P02400) |
| 3. | YN03H01172P1 | [1] | ELBOW,1-3/16" - 12 ORFS x 3/4" ORB | KOB90° -- 1-3/16"-12UN x 3/4 PF x 116mm Long (Incls. O-Ring ZD12P02400) |
| 4. | ZD12A01800 | [4] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
