纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-069[02]) - GUARD INSTAL (COMMON) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
684 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8. | YN21C03137F1 | [1] | GUARD | KOB Superseded by part number: YN21C03282P1, YN21C03473P1, YN21C03284P1, YN21C03283P1 |
| 9. | YN21C03575P1 | [1] | GUARD | KOB |
| 10. | YN21C03246P1 | [1] | PLATE | KOB |
| 11. | YN21C03613P1 | [1] | GUARD | KOB |
| 12. | YN21C03455P1 | [1] | GUARD | KOB |
| 13. | YN21C03599P1 | [1] | GUARD | KOB |
| 14. | YN21C03608F1 | [1] | COVER ASSY | KOB Superseded by part number: YN21C03610P1, YN21C03463P1, YN21C03609P1 |
| 15. | YN21C02423P1 | [1] | PLATE | KOB |
| 16. | YN21C02410P1 | [1] | BRACKET | KOB |
| 17. | YN21C01716P1 | [1] | PLATE | KOB |
| 18. | YN21C02791P1 | [1] | SPRING | KOB |
| 19. | YN21C02792P1 | [1] | SPRING | KOB |
| 21. | YN21C04124P1 | [1] | STRIKER | KOBSTRIKER |
| 23. | YN21C02750P1 | [1] | STAY | KOB |
| 24. | YN21C03374P1 | [1] | BRACKET | KOB |
| 25. | YN21C03466P1 | [1] | PLATE | KOB |
| 26. | ZW16P16000 | [1] | WASHER | KOBID 17 x OD 30 x Th 3.0mm |
| 27. | 2419R9D6 | [1] | PIN | KOB |
| 28. | YN21C03212P1 | [4] | STOP | KOB |
| 29. | ZN18F10008 | [4] | NUT | KOBM10x1.25mm |
| 30. | ZS18C12025 | [4] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 31. | 2418T10357 | [6] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| 35. | YN21C02138P1 | [2] | WASHER | KOBID 12.40 x OD 38 x Th 6.0mm |
| 36. | YN21C02147P1 | [2] | WASHER | KOBID 17.60 x OD 32.50 x Th 1.5mm |
| 40. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBM08x1.25x25mm (Incls. Washer) |
| 41. | ZM73C10020 | [5] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
| 42. | ZM73C12025 | [44] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
| 43. | ZM73C12030 | [10] | BOLT,M12x30mm - Course Thread | KOBM12x1.75x30mm (Incls. Washer) |
| 46. | YN21C03776P1 | [1] | SHIM | SM Superseded by part number: 84529272 |
| 50. | YN21C03553P3 | [1] | PILLAR | KOB |
