纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-069[03]) - GUARD INSTAL (COMMON) TOOL BOX ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
876 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN21C03848P1 | [1] | PANEL ASSY. | KOB Superseded by part number: 87619048 |
| 1.1. | YN21C03803P1 | [1] | LOCK | SM Superseded by part number: YN21C04959P1 |
| 3. | YN21C03741P1 | [1] | BRACKET | KOB |
| 4. | YN21C03743P1 | [1] | RUBBER SEAL | KOB Superseded by part number: 87560623 |
| 5. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 6. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 7. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
| 8. | 2418T12346 | [4] | WASHER | KOBID 11 x OD 30 x Th 3.2mm |
| 9. | YJ21C01079D6 | [5] | INSULATING PANEL | KOB |
| . . | YN21C03212P1 | [1] | STOP | KOBDoor Stop, Not Shown |
| . . | ZN18F10008 | [1] | NUT | KOBNut for Door Stop, Not Shown, M10x1.25mm |
