纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-073[00]) - COVER ASSY, UNDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
523 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | YN24C01374P1 | [1] | COVER | SM |
| 4. | YN24C01271P1 | [1] | COVER | KOB530 x 210mm |
| 5. | YN24C01311F1 | [1] | COVER ASSY | KOBIncls. Refs. 5-1 - 5-4 |
| 5-1. | YN24C01312P1 | [1] | COVER | KOB(Part of YN24C01311F1) |
| 5-2. | 2427P1836D14 | [1] | WEATHERSTRIP | KOB(Part of YN24C01311F1), 580mm Long (22-53/64 in) |
| 5-3. | 2427P1836D5 | [1] | EXTRUSION | KOB(Part of YN24C01311F1) |
| 5-4. | PM21C01152D5 | [2] | WEATHERSTRIP | KOB(Part of YN24C01311F1), 160mm Long (6-9/32 in) |
| 6. | YN24C01335F1 | [1] | COVER ASSY | KOBIncls. Refs. 6-1 - 6-3 |
| 6-1. | YN24C01336P1 | [1] | COVER | KOB(Part of YN24C01335F1) Superseded by part number: LQ24C01177P1 |
| 6-2. | 2427P1836D25 | [2] | WEATHERSTRIP | KOB(Part of YN24C01335F1), 410mm Long (16-9/64 in) |
| 6-3. | 2427P1836D19 | [2] | WEATHERSTRIP | KOB(Part of YN24C01335F1), 385mm Long (15-5/32 in) |
| 7. | YN24C01266F1 | [1] | COVER ASSY | KOBIncls. Refs. 7-1 & 7-2 |
| 7-1. | YN24C01261P1 | [1] | COVER | KOBCover (Part of YN24C01266F1) |
| 7-2. | PM21C01136DR | [1] | WEATHERSTRIP | KOB(Part of YN24C01266F1) |
| 8. | YN24C01341P1 | [1] | COVER | KOB |
| 9. | ZM73C12030 | [26] | BOLT,M12x30mm - Course Thread | KOBM12x1.75x30mm (Incls. Washer) |
| 10. | ZM73C12025 | [8] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
