纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-074[01]) - PANEL ASSY, INSTRUMENT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
824 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN17M01432F1 | [1] | COVER | SM Superseded by part number: YN20M01779P2, YN20M01780P2, YN17M01432F2 |
| 3. | YN17M01464P2 | [1] | COVER | KOB |
| 4. | YN17M01435F1 | [1] | SUPPORT | SM Superseded by part number: YN17M01435F2 |
| 5. | YN17M01438F1 | [1] | COVER ASSY | SM Superseded by part number: YN17M01438F2 |
| 6. | YN17M01437P1 | [1] | PLUG | SM |
| 7. | YN17M01436F1 | [1] | COVER ASSY | SM Superseded by part number: YN17M01436F2 |
| 8. | YN17M01439F1 | [1] | COVER | SM |
| 9. | YN17M01440F1 | [1] | COVER | SM Superseded by part number: YN17M01440F2 |
| 10. | YN17M01441F1 | [1] | COVER | SM |
| 11. | YN17M01442F1 | [1] | COVER | SM Superseded by part number: YN17M01442F2 |
| 12. | YN17M01443F1 | [1] | COVER | SM Superseded by part number: YN17M01443F2 |
| 13. | YN20M01773F1 | [1] | DUCT | SM Superseded by part number: YN20M01773F2 |
| 14. | YN20M01812P1 | [1] | DUCT | KOB |
| 15. | YN20M01813P1 | [1] | DUCT | KOB, Years: -07-MAR-14 |
| 15. | YN20M01813P2 | [1] | DUCT | KOB, Start Year: 07-MAR-14 |
| 16. | YN20M01774F1 | [1] | DUCT | SM |
| 17. | YN20M01779P1 | [1] | DUCT | SM Superseded by part number: YN20M01779P2, YN20M01780P2, YN17M01432F2 |
| 18. | YN20M01780P1 | [1] | DUCT | SM Superseded by part number: YN20M01780P2 |
| 19. | YN17M01480P2 | [1] | BRACKET | KOB |
| 26. | LQ58S00002P1 | [1] | HOURMETER | SM |
| 27. | PU20M01002P1 | [1] | CONVEYOR | SM |
| 28. | YN20M01791P1 | [2] | CONVEYOR | SM |
| 33. | YN17M01448P1 | [1] | BRACKET | SM Superseded by part number: YN17M01448P2 |
| 38. | ZM66C06020 | [21] | BOLT | KOBM06x1.0x20mm (Incls. Washer & Lockwasher) |
| 41. | YN81S01002P1 | [1] | SEAT/SLOT,12V | SM |
| 42. | ZM73C06016 | [8] | BOLT,M6x16mm - Course Thread | KOBM06x1.0x16mm (Incls. Washer) |
| 43. | YN17M01162D2 | [1] | SCREW | SM |
| 44. | ZM61C05012 | [4] | BOLT | KOBM05x0.8x12mm (Incls. Washer & Lockwasher) |
| 45. | ZN12C06005 | [2] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 49. | NSS | [1] | NOT SERVICED SEPARATELY | CONSee Ref 42 |
