现代零件查询R35Z-7 ADJUST COMPONENT(#0325-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
664 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| N . |
81MH-15053
|
[1] |
ADJUST COMPONENT-LH
|
|
| N . |
81MH-15063
|
[1] |
ADJUST COMPONENT-RH
|
|
| N . |
81MH-15022
|
[1] |
ADJUST COMPONENT-LH
|
|
| N . |
81MH-15032
|
[1] |
ADJUST COMPONENT-RH
|
|
| 1. |
81MH-13071
|
[1] |
IDLER ASSY
|
|
| 1. |
81MH-13041
|
[1] |
IDLER ASSY
|
|
| 1-1. |
81MH-13700
|
[1] |
SHELL
|
|
| 1-1. |
81MH-13400
|
[1] |
SHELL
|
|
| 1-2. |
81MH-13711
|
[2] |
SHAFT
|
|
| 1-3. |
81MH-13732
|
[1] |
COLLAR-LH
|
|
| 1-4. |
81MH-13750
|
[1] |
COLLAR-RH
|
|
| 1-5. |
81MK-13320
|
[2] |
BUSHING
|
|
| 1-6. |
81MK-13340
|
[2] |
SEAL ASSY
|
|
| 1-7. |
81MK-13370
|
[2] |
O-RING
|
|
| 1-8. |
81MH-13780
|
[2] |
SPRING PIN
|
|
| 1-9. |
81MJ-13390
|
[2] |
PLUG-HEX
|
|
| 2. |
81MH-14052
|
[1] |
TENSION CYLINDER-LH
|
|
| 2. |
81MH-14062
|
[1] |
TENSION CYLINDER-RH
|
|
| 2. |
81MH-14020
|
[1] |
TENSION CYLINDER-LH
|
|
| 2. |
81MH-14030
|
[1] |
TENSION CYLINDER-RH
|
|
| 2-1. |
81MH-14201
|
[1] |
BODY ASSY
|
|
| 2-2. |
81MH-14210
|
[1] |
ROD ASSY-LH
|
|
| 2-2. |
81MH-14310
|
[1] |
ROD ASSY-RH
|
|
| 2-3. |
81MH-14220
|
[1] |
SPRING-TENSION
|
|
| 2-4. |
81MH-18052
|
[1] |
YOKE
|
|
| 2-5. |
81MH-14240
|
[1] |
NUT
|
|
| 2-6. |
S461-630562
|
[1] |
PIN-SPLIT
|
|
| 2-7. |
81EL-20090
|
[1] |
VALVE-GREASE
|
|
| 2-8. |
81MH-14260
|
[1] |
O-RING
|
|
| 2-9. |
81MH-14270
|
[1] |
RING-BACKUP
|
|
| 2-10. |
81MH-14280
|
[1] |
PACKING
|
|
| 2-11. |
S017-100256
|
[2] |
BOLT-HEX
|
|
| 2-12. |
81MH-14290
|
[1] |
SPACER
|
|
| 2-13. |
81MH-14240
|
[1] |
NUT
|
|
| 4. |
S015-080456
|
[4] |
BOLT-HEX
|
|
| 5. |
S411-080002
|
[4] |
WASHER-SPRING
|
|
