神钢零件查询(K903A) - EXCAVATOR BTW K2748 - K3928 (1/76-12/03) (09-010) - BUCKET ASSY, EJECTOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
239 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X355F3 | [1] | BUCKET ASSY, EJECTOR, CONSISTS OF REF. 3 TO 20 | |
| 3. | 2406N389 | [1] | LINK, EJECTOR | |
| 9. | 2420T2446 | [2] | CAPSCREW | |
| 10. | ZN21C12015 | [2] | NUT | |
| 13. | ZP15D03025 | [2] | COTTER PIN | KOBCOTTER-PIN Superseded by part number: ZP15D03035 |
| 14. | ZS83C12018 | [2] | SETSCREW | |
| 15. | 2406N388F2 | [1] | LINK, BUCKET, INCL. REF. 15-14 TO 15-18 | |
| 15-14. | 2405T596 | [2] | BUSHING | |
| 15-15. | 2405T594 | [2] | BUSHING | |
| 15-16. | 2405T629 | [2] | BUSHING | |
| 15-17. | 2445R138D1 | [6] | SEAL,50mm ID x 65mm OD x 4mm Thk | KOBDust -- ID 50 x OD 65 x Th 4mm |
| 15-16. | 2422V001 | [1] | PLUG | |
| 16. | 2412J217F2 | [1] | EJECTOR, INCL. REF. 16-15 TO 16-17 | |
| 16-15. | 2405T629 | [2] | BUSHING | |
| 16-16. | 2405T630 | [2] | BUSHING | |
| 16-17. | 2422V001 | [2] | PLUG | |
| 18. | 24100T46F2 | [1] | BUCKET ASSY, EJECTOR, CONSISTS OF REF. 18-2 & 18-3 | |
| 18-2. | B12P0015F1 | [2] | TOOTH | KOBASSY., CONSISTS OF REF. 18-2A TO 18-2C |
| 18-2A. | B12P0015E1 | [1] | BUCKET TOOTH POINT | KOB |
| 18-28. | B12P0015E2 | [1] | PIN | KOB Superseded by part number: 2412Z162K |
| 18-2C. | B12P0015E3 | [1] | LOCK PIN | KOB Superseded by part number: B12P0015E3MK |
| 18-3. | 2412J276F1 | [1] | BUCKET, EJECTOR, CONSISTS OF REF. 18-3A & 18-3R | |
| 18-3A. | 2412J276 | [1] | BUCKET, EJECTOR, CONSISTS OF REF. 18-3P TO 18-3P | |
| 18-3P. | 2412N214 | [2] | ADAPTER | KOB |
| 18-3R. | 2405T708 | [1] | BUSHING | |
| 19. | 2419P760F2 | [1] | PIN, INCL. REF 19-4 | |
| 19-4. | 2691S02000 | [1] | FITTING, GREASE | |
| 20. | 2419P759F3 | [1] | PIN, INCL. REF. 20-5 | |
| 20-5. | 2691502000 | [2] | FITTING, GREASE | |
