纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (08-30-02[00]) - VALVE ASSEMBLY, SOLENOID (YN35V00051F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
473 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN35V00051F1 | [1] | SOLENOID VALVE | KOBAssembly, Solenoid |
| 311. | NSS | [1] | NOT SERVICED SEPARATELY | CONSpool |
| 361. | YN35V00004S361 | [1] | O-RING | KOB |
| 362. | YN35V00004S362 | [1] | O-RING | KOB |
| 363. | YN35V00004S363 | [1] | O-RING | KOB |
| 802. | YN35V00018S802 | [1] | NUT | KOB |
| 861. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
