纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-01-00[02]) - UPPER FRAME ASSEMBLY, PAGE 2 OF 2 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
967 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| B3. | ZN18F20016 | [1] | NUT | KOBM20x1.50mm |
| B4. | ZS18F20085 | [1] | CAPTIVE WASHER SCREW,Hex, M20 x 85mm | KOBM20x1.50x85mm |
| B8. | YR52F01080D7 | [5] | RUBBER SEAL | KOB Superseded by part number: YY52F01567D5 |
| B9. | YR52F01086D3 | [1] | RUBBER SEAL | KOB |
| B10. | PF64H01015D6 | [1] | RUBBER SEAL | KOB |
| B12. | YT64H01029D7 | [1] | RUBBER | KOB |
| B13. | YT68H01031P1 | [1] | GROMMET | KOB |
| B14. | YT32H01066P1 | [1] | GROMMET | KOB |
| B15. | YT13E01120P1 | [1] | GROMMET | KOB |
| B16. | PH13E01071P1 | [2] | GROMMET | KOB |
| B17. | 2420Z1234 | [2] | GROMMET | KOB |
| B18. | YT52F01189P1 | [2] | INSULATION | KOBInsulation |
| B19. | 2420R766D4 | [1] | GROMMET | KOB |
| B21. | YT52F01266P1 | [1] | GROMMET | KOB |
| B22. | YT52F01257P1 | [1] | INSULATION | KOBInsulation |
| B23. | YT52F01258P1 | [1] | INSULATION | KOBInsulation |
| B24. | YT52F01259P1 | [1] | INSULATION | KOBInsulation |
| B25. | YT64H01029D2 | [1] | RUBBER | KOB |
| B26. | YT64H01029DD | [1] | RUBBER SEAL | KOB |
| B27. | YR52F01080DE | [2] | RUBBER SEAL | KOB Superseded by part number: YY52F01567D5 |
| B28. | YT52F01267P1 | [1] | INSULATION | KOBInsulation |
| B29. | YT52F01268P1 | [1] | INSULATION | KOBInsulation |
| B30. | YT52F01269P1 | [1] | INSULATION | KOBInsulation |
