| A2. | 2420R537D135 | [1] | FLEXIBLE HOSE,9.60mm ID x 1350mm L | KOB1350mm Long (53-9/64 in) Superseded by part number: HX21E06135DX |
| A3. | LS68H01016D1 | [1] | HOSE,6.3mm ID x 1350mm L | KOB1350mm Long (53-9/64 in) |
| A4. | 2420R537D140 | [1] | HOSE ASSY.,9.60mm ID x 1400mm L | KOB1400mm Long (55-7/64 in) |
| A5. | LS68H01016D4 | [1] | HOSE,6.3mm ID x 1400mm L | KOB1400mm Long (55-1/8 in) |
| A7. | HX23L04280CB | [1] | FLEXIBLE HOSE | KOB2800mm Long (110-1/4 in) |
| A9. | HX23L04270CH | [1] | FLEXIBLE HOSE | KOB2700mm Long (106-19/64 in) |
| A10. | HX23L04290CH | [1] | FLEXIBLE HOSE | KOB2900mm Long (114-11/64 in) |
| A11. | HX23L04290CR | [1] | FLEXIBLE HOSE | KOB2900mm Long (114-11/64 in) |
| A12. | HX23L04290CB | [1] | FLEXIBLE HOSE | KOB2900mm Long (114-11/64 in) |
| A13. | HX23L04350CG | [1] | FLEXIBLE HOSE | KOB3500mm Long (137-51/64 in) |
| B1. | 2420R349D028 | [1] | HOSE,280.00 mm | KOB280mm Long (11-1/32 in) Superseded by part number: 2420R349D030 |
| B2. | 2420R349D052 | [1] | FLEXIBLE HOSE | SM520mm Long (20-15/32 in) Superseded by part number: 2420R349D055 |
| B3. | 2420R349D072 | [1] | FLEXIBLE HOSE | SMHose -- 720mm Long (28-11/32 in) Superseded by part number: 24820R63D072 |
| B4. | ZH32X04000 | [3] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- (Incls. O-Ring 237-6004) |
| . . | 237-6004 | [1] | O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro | CAS(Part of ZH32X04000), SAE No. 4-1, Not Shown Superseded by part number: 72186131, 165202 |
| B5. | ZH42X04000 | [3] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| B6. | ZE72X04000 | [3] | PLUG | KOB(Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of ZE72X04000), ID 10.80 ± 0.18 x OD 15mm, Not Shown |
| B7. | YT64H01032P1 | [1] | BLOCK | KOB |
| B8. | YX52S00013P1 | [3] | SENSOR | SMPressure (Low Pressure) (Incls. O-Ring ZD12P01100), Incls. Refs. B8-2 Superseded by part number: LC52S00019P1 |
| B9. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| B10. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
