纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-27-10[00]) - REMOTE CONTROL LINES (DOZER) (YT68H00064F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
895 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT30V00046F1 | [1] | PILOT VALVE | KOBAssembly -- See Figure 08-27-00 |
| 2. | 2420R349D100 | [1] | HOSE | KOB1000mm Long (39-3/8 in) Superseded by part number: HX21E04100DX |
| 3. | 2420R349D210 | [1] | FLEXIBLE HOSE | KOB2100mm Long (82-11/16 in) |
| 4. | 2420R349D240 | [1] | HOSE,2400.00 mm | KOB Superseded by part number: HX21E04240DX |
| 5. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring 237-6004) |
| . . | 237-6004 | [1] | O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro | CAS(Part of ZH22X04000), SAE No. 4-1, Not Shown Superseded by part number: 72186131, 165202 |
| 6. | HH35X04004G3 | [1] | 90 ELBOW | KOB90° (with Filter) -- 1/4"PF (Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of HH35X04004G3), ID 10.80 ± 0.18 x OD 15mm, Not Shown |
| 8. | ZH32X04000 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- (Incls. O-Ring 237-6004) |
| 9. | 2444T2592 | [1] | TEE | KOB3/8" PF - 1/4" PF (No O-Ring supplied) |
| 10. | 2444Z2544 | [1] | TEE | KOB1/4"PTx60mm Long (No O-Ring supplied) |
| 12. | HM83C10030G1 | [2] | BOLT | KOBM10x30mm |
| 13. | YN68H01106P1 | [1] | COVER | KOB |
| 15. | 2420R349D105 | [1] | HOSE,1050.00 mm | KOB |
