神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (06-002) - HYDR LINES, LOW (BLADE) (FOR EXPORT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
290 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J4891F1 | [1] | HYDR LINES, LOW | |
| 1. | 2418N2196D1 | [1] | TUBE | KOB |
| 2. | 2418N2196D2 | [1] | TUBE | TUBE |
| 3. | 2418T10104 | [1] | TUBE | |
| 4. | 2418T10101 | [1] | TUBE | |
| 5. | 2418T10103 | [2] | TUBE | |
| 6. | 2418T10102 | [2] | TUBE | |
| 7. | ZX27N06036 | [4] | HOSE | KOB |
| 8. | ZK23F15006 | [2] | CONNECTOR | CONNECTOR |
| 9. | ZK23G15006 | [4] | CONNETOR | |
| 10. | NSS | [2] | NOT SOLD SEPARAT | CONTEE |
| 11. | 2432T1773 | [4] | CLAMP | KOB |
| 12. | ZS13C08085 | [2] | CAPSCREW | CAPSCREW |
| 13. | ZN12C08007 | [4] | NUT | KOBM08x1.25mm Superseded by part number: 77278252, ZN18C08007 |
| 14. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
