| A1. | 2420R349D046 | [1] | FLEXIBLE HOSE | KOBHose -- 460mm Long (18-7/64 in) Superseded by part number: 2420R349D050 |
| A4. | 2444R963D38 | [1] | FLEXIBLE HOSE | KOB1100mm Long (43-19/64 in) |
| A6. | 2444Z2894 | [2] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of 2444Z2894), ID 10.80 ± 0.18 x OD 15mm, Not Shown |
| A7. | ZH32X04000 | [17] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- (Incls. O-Ring 237-6004) |
| . . | 237-6004 | [1] | O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro | CAS(Part of ZH32X04000), SAE No. 4-1, Not Shown Superseded by part number: 72186131, 165202 |
| A8. | 2444Z3155 | [2] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB90° -- (Incls. O-Ring ZD12P01400) Superseded by part number: YT42H01128P1 |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of 2444Z3155), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| A10. | ZH42X06000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring 237-6006) |
| . . | 237-6006 | [1] | O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro | CAS(Part of ZH42X06000), SAE No. 6-1, Not Shown Superseded by part number: 9617873 |
| A11. | ZH32X04006 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- (Incls. O-Ring 237-6006) |
| A15. | 2444Z2525 | [7] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) |
| A16. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring 237-6004) |
| A17. | YX52S00013P1 | [1] | SENSOR | SMPressure (Low Pressure) (Incls. O-Ring ZD12P01100), Incls. Refs A17-2 Superseded by part number: LC52S00019P1 |
| A18. | YT06H01019P1 | [1] | GUIDE | KOBGuide |
| A19. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| A20. | ZM73C12025 | [1] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
| A21. | HH55Q06006G1 | [1] | TEE | KOB(Incls. O-Ring ZD12P01400) |
| A22. | HX33L04048DY | [1] | FLEXIBLE HOSE | KOB480mm Long (18-57/64 in) |
| A23. | ZH22X04006 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| B1. | ZE72X06000 | [1] | PLUG | KOB(Incls. O-Ring ZD12P01400) |
