纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-35-01[00]) - MIRROR INSTALLATION (REAR) (YT52C00018F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
718 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YF52C00007P1 | [2] | MIRROR | KOB |
| 2. | YT52C01043P1 | [1] | STAY | KOBStay |
| 3. | YT52C01044P1 | [1] | STAY | KOBStay |
| 4. | YT52C01040P1 | [1] | BRACKET | KOB |
| 5. | YT52C01075P1 | [2] | BUSHING | KOB |
| 6. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| 7. | 2418T12346 | [6] | WASHER | KOBID 11 x OD 30 x Th 3.2mm |
| 8. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
| 9. | R16T0137D3 | [8] | WASHER | KOBCone Disk Spring -- ID 10.2 x OD 20 x Th 0.8mm |
| 10. | ZM73C12035 | [2] | BOLT,M12x35mm - Course Thread | KOBM12x1.75x35mm (Incls. Washer) |
| 11. | YT52C01074P1 | [1] | PLATE | KOB |
| 12. | ZM73C06016 | [2] | BOLT,M6x16mm - Course Thread | KOBM06x1.0x16mm (Incls. Washer) |
