神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (08-007) - RADIATOR ASSY P/N 2452U221F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
843 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2452U221F2 | [1] | RADIATOR | RADIATOR |
| 1. | 2452U221S20 | [1] | CORE | CORE |
| 1-1. | 2452U221S1-1 | [1] | RADIATOR | |
| 1-2. | 2452U221S1-2 | [8] | BOLT | KOB |
| 1-8. | 2452U221S1-8 | [1] | COCK | KOB Superseded by part number: 2452U221S18 |
| 1-9. | 2452U221S1-9 | [1] | TUBE, VINYL | |
| 1-10. | 2452U221S110 | [1] | FRAME | |
| 1-11. | 2452U221S111 | [1] | CAP | KOB Superseded by part number: 2414Z262 |
| 1-12. | 2452U221S112 | [1] | HOSE | KOBFRAME |
| 1-13. | 2452U221S113 | [2] | CLIP | KOB Superseded by part number: 2452U267S8 |
| 1-14. | 2452U221S114 | [1] | SHROUD | |
| 2. | 2452U221S2 | [5] | BOLT | BOLT |
| 3. | 2452U221S3 | [1] | COOLER | COOLER |
| 4. | 2452U221S7 | [2] | PACKING | PACKING |
