神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (08-008) - TANK ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
719 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2753F1 | [1] | TANK , ASSY | |
| 1. | 2427U203F1 | [1] | CONTAINER | KOB |
| 2. | 2420Z912D3 | [2] | FLEXIBLE HOSE | KOB |
| 3. | 2416P7196 | [1] | BRACKET | |
| 4. | 2416T10844 | [1] | BRACKET | KOB |
| 5. | ZS16C08030 | [2] | CAPSCREW M08x1.25x30mm | CAPSCREW M08x1.25x30mm |
| 6. | ZN16C08007 | [2] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 7. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 8. | 2414Z262 | [1] | PLUG | KOB |
| 9. | ZC15X01300 | [2] | CLIP | KOB |
