纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-45-01[01]) - GUARD ASSEMBLY (RIGHT) (YT21C00039F1), PAGE 1 OF 3 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
642 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | ZM73C12025 | [11] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
| 4. | YT21C01849F1 | [1] | COVER ASSY | KOBPanel Assembly, Incls. Refs. 4-1 - 4-3 |
| 4-1. | YT21C01910P1 | [1] | PANEL | KOB |
| 4-2. | YJ21C01080DB | [1] | WEATHERSTRIP | KOB |
| 4-3. | YT21C01885P1 | [1] | INSULATION | KOBInsulation |
| 6. | YT21C01875F1 | [1] | STRIKER | KOBStriker Assembly, Incls. Refs. 6-1 - 6-3 |
| 6-1. | YT21C01872P1 | [1] | BRACKET | KOBBracket Superseded by part number: YT21C01872P2 |
| 6-2. | YF21C01705P1 | [1] | PIN | KOB |
| 6-3. | ZR36X00700 | [1] | RING | KOBRetaining -- Shaft 07mm x OD 14mm |
| 10. | YF21C01782D1 | [2] | SHIM | KOB |
| 15. | YT21C01943P1 | [1] | GROMMET | KOB |
