纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-45-02[00]) - GUARD INSTALLATION, (INSIDE) (YT21C00026F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
595 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YR21C01397F1 | [1] | COVER ASSY | KOBIncls. Refs. 1-1 - 1-8 |
| 1-1. | YR21C01398P1 | [1] | Cover | |
| 1-2. | PE21C01135DF | [1] | TRIM | KOB |
| 1-3. | YJ21C01103D4 | [1] | INSULATING PANEL | KOBStrip, Weather |
| 1-4. | YR21C01168DD | [2] | WEATHERSTRIP | KOBWeatherstrip -- 200mm Long (7-7/8 in) |
| 1-5. | YR21C01168DJ | [1] | WEATHERSTRIP | KOB165mm Long (6-1/2 in) |
| 1-6. | YJ21C01103D7 | [1] | WEATHERSTRIP | KOB |
| 1-7. | YR21C01404P1 | [1] | RUBBER SEAL | KOB |
| 1-8. | YT21C01876P1 | [1] | INSULATION | KOBInsulation |
| 2. | YT21C01856F1 | [1] | COVER ASSY | KOBIncls. Refs. 2-1 - 2-3 |
| 2-1. | YT21C01831P1 | [1] | Cover | |
| 2-2. | YR21C01168D1 | [1] | WEATHERSTRIP | KOB480mm Long (18-57/64 in) |
| 2-3. | YT21C01877P1 | [1] | Insulation | |
| 3. | YT21C01860F1 | [1] | COVER ASSY | KOBIncls. Refs. 3-1 & 3-2 |
| 3-1. | YT21C01861P1 | [1] | COVER | KOBCover |
| 3-2. | YT21C01878P1 | [1] | INSULATION | KOBInsulation |
| 4. | YT21C01705F1 | [1] | COVER ASSY | KOBIncls. Refs. 4-1 - 4-3 |
| 4-1. | YT21C01706P1 | [1] | COVER | KOBCover |
| 4-2. | PE21C01135DG | [1] | TRIM | KOB |
| 4-3. | YR21C01168DB | [1] | WEATHERSTRIP | KOB250mm Long (9-27/32 in) |
| 6. | ZM73C08016 | [2] | BOLT,M8x16mm - Course Thread | KOBM08x1.25x16mm (Incls. Washer) |
| 7. | ZM73C12020 | [4] | BOLT,M12x20mm - Course Thread | KOBM12x1.75x20mm (Incls. Washer) |
| 8. | ZM73C12025 | [6] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
| 9. | ZM73C12030 | [1] | BOLT,M12x30mm - Course Thread | KOBM12x1.75x30mm (Incls. Washer) |
