神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (08-022) - INSTAL, HEATER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
344 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2334F1 | [1] | INSTAL, HEATER | |
| 1. | R79N0007 | [1] | HEATER | KOB |
| 2. | 2416P5414 | [1] | BRACKET | BRACKET |
| 3. | 2420Z699 | [1] | GROMMET | KOB |
| 4. | ZM11C10020 | [2] | SCREW | KOBM10x1.50x20mm (Incls. Lockwasher) Superseded by part number: ZM12C10020 |
| 5. | R18T0026D11 | [7] | HOSE | HOSE |
| 6. | 2432Z290 | [5] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 7. | 2444Z1633 | [1] | COCK | KOB Superseded by part number: PH21M01008P1 |
| 8. | 2444Z1630 | [1] | FITTING | KOBConnector -- 3/8" PT Hose |
| 9. | R16T0238D1 | [4] | CLIP | KOB |
| 10. | 2444Z1632 | [1] | COCK | COCK |
| 15. | 2414Z199D25 | [1] | PROTECTIVE SLEEVE | KOB Superseded by part number: 2414Z199D025 |
