神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (08-023) - HEATER ASSY (FOR COLD REGIONS) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
266 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6030F3 | [1] | HEATER ASSY | |
| 1. | 2479U319 | [1] | HEATER, CAB | |
| 2. | 2416T12971 | [1] | BRACKET | |
| 3. | ZS16C10020 | [4] | CAPSCREW M10x1.50x20mm | CAPSCREW M10x1.50x20mm |
| 4. | ZN16C10008 | [4] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 5. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 6. | ZW22X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 9. | 2422P647 | [1] | PLATE, FLOOR | |
