神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (08-024) - HEATER & DEFROSTER (FOR EXPORT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
357 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J4978F2 | [1] | HEATER & DEFROSTER | |
| 1. | 24100P1066F1 | [1] | HEATER ASSY | HEATER ASSY |
| 1-1. | 2479U371 | [1] | HEATER | KOB |
| 1-2. | 2416T10995 | [1] | BRACKET | BRACKET |
| 1-3. | 2406T1681 | [1] | LEVER | LEVER |
| 1-4. | 2418T10746 | [1] | PLATE | PLATE |
| 1-5. | 2406Z299 | [1] | WIRE HARNESS | KOB |
| 1-6. | 2406Z298 | [1] | WIRE HARNESS | KOB |
| 1-7. | 2432Z436 | [2] | CLAMP | CLAMP |
| 2. | 2434Z163 | [2] | NOZZLE | KOBASSY |
| 3. | 2444Z2158 | [2] | SOCKET | KOB |
| 4. | 2444Z2227 | [2] | HYD CONNECTOR | KOB |
| 5. | 2444Z2156D4 | [2] | HOSE | KOB |
| 6. | 2416T10935 | [1] | BRACKET | |
| 7. | 2444Z2220D3 | [2] | HOSE | KOB |
| 8. | 2418T10455 | [2] | PIPE | KOB |
| 9. | ZC15X02300 | [6] | CLIP | KOB |
| 10. | 2420Z699 | [3] | GROMMET | KOB |
| 11. | ZM11C10020 | [2] | SCREW | KOBM10x1.50x20mm (Incls. Lockwasher) Superseded by part number: ZM12C10020 |
| 12. | ZM11C10025 | [4] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 13. | ZS18C16025 | [2] | SCREW,Hex, M16 x 25mm | KOBM16x2.0x25mm |
| 15. | ZW26X06000 | [7] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 16. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 17. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 22. | 2427Z518 | [1] | MAT, FLOOR LE3 4, Serial Range: 01-LE4402 | |
| 23. | 2427Z519 | [1] | MAT, FLOOR LE3 4, Serial Range: 01-LE4402 | |
| 24. | 2427Z516 | [1] | MAT, FLOOR LE3 4, Serial Range: 01-LE4402 | |
| 25. | 2427Z517 | [1] | MAT, FLOOR LE3 4, Serial Range: 01-LE4402 | |
| 26. | 2444Z2220D4 | [1] | HOSE | KOB |
| 27. | 2436Z390 | [1] | HYDRAULIC VALVE | KOB |
| 28. | ZS16C08016 | [2] | SCREW | KOBM08x1.25x16mm Superseded by part number: ZS18C08016 |
| 29. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 30. | ZN16C08007 | [2] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 31. | ZS31C04010 | [2] | SCREW,Phillips Drive, Pan HD, M4 x 10mm | KOBM04x0.7x10mm |
| 32. | ZW26X04000 | [2] | LOCK WASHER | KOBID 04 x OD 7.6 x Th 1.0mm |
| 42. | 2444Z1630 | [1] | FITTING | KOBConnector -- 3/8" PT Hose |
| 45. | 2444Z1633 | [1] | COCK | KOB Superseded by part number: PH21M01008P1 |
| 47. | 2444Z1632 | [1] | COCK | COCK |
| 49. | R18T0026D11 | [2] | HOSE | HOSE |
| 53. | 2414Z199D25 | [1] | PROTECTIVE SLEEVE | KOB Superseded by part number: 2414Z199D025 |
| 54. | R16T0238D1 | [4] | CLIP | KOB |
