纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-45-03[02]) - GUARD INSTALLATION (TOP) (YT21C00037F1), PAGE 2 OF 3 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
537 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | YT22C00013F1 | [1] | COVER ASSY | KOBIncls. Refs. 2-1 - 2-17 Superseded by part number: YT22C00019F1 |
| 2-1. | YT22C01180P1 | [1] | COVER | KOB |
| 2-2. | YT22C01205P1 | [1] | INSULATION | KOB |
| 2-3. | YT22C01175P1 | [1] | INSULATION | KOB |
| 2-4. | YT22C01174P1 | [1] | INSULATION | KOB Superseded by part number: YT22C01246P1 |
| 2-5. | YT22C01173P1 | [1] | INSULATION | KOB Superseded by part number: YT22C01245P1 |
| 2-6. | YT22C01204P1 | [1] | INSULATION | KOB |
| 2-7. | YT21C01034P2 | [1] | CATCH | KOB |
| 2-8. | YT21C01090F3 | [1] | LOCK | KOBAssembly, Incls. Refs. 2-8A & 2-8D |
| 2-8A. | YR22C01025P2 | [1] | LOCK | KOB |
| 2-8D. | YT21C01801P1 | [1] | PLATE | KOBPlate |
| 2-9. | PM02C01035DA | [1] | WEATHERSTRIP | KOB |
| 2-10. | 2427Z2106D3 | [1] | WEATHERSTRIP | KOB |
| 2-11. | ZM73C06016 | [2] | BOLT,M6x16mm - Course Thread | KOBM06x1.0x16mm (Incls. Washer) |
| 2-12. | YT21C01907P1 | [1] | ROD | KOB |
| 2-13. | YT21C01053P1 | [1] | CLIP | KOB |
| 2-15. | YT22C01230P1 | [1] | RUBBER SEAL | KOB |
| 2-16. | ZS41C05020 | [3] | SCREW,M5 x 20mm | KOBMachine -- M05x0.8x20mm |
| 2-17. | YT22C01216P1 | [1] | INSULATION | KOB |
| 5. | YT21C01795P1 | [1] | STAY | KOBStay |
| 6. | YT21C01796P1 | [1] | BRACKET | KOB |
| 7. | YT21C01898P1 | [1] | STRIKER | KOBStriker Superseded by part number: LG21C01443F1 |
| 10. | ZW16P10000 | [1] | WASHER | KOBID 05 x OD 10 x Th 2.0mm |
| 11. | 2419R9D3 | [1] | PIN | KOBSnap --ND 10mm x 32.6mm Long |
| 13. | ZM73C12025 | [10] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
| 17. | YF21C01782D1 | [2] | SHIM | KOB |
