神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (08-025) - HEATER ASSY (FOR EXPORT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
785 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J5064F12 | [1] | HEATER ASSY | |
| 4. | 24100P1066F1 | [1] | HEATER ASSY | HEATER ASSY |
| 4-1. | 2479U371 | [1] | HEATER | KOB |
| 4-2. | 2416T10995 | [1] | BRACKET | BRACKET |
| 4-3. | 2406T1681 | [1] | LEVER | LEVER |
| 4-4. | 2418T10746 | [1] | PLATE | PLATE |
| 4-5. | 2406Z299 | [1] | WIRE HARNESS | KOB |
| 4-6. | 2406Z298 | [1] | WIRE HARNESS | KOB |
| 4-7. | 2432Z436 | [2] | CLAMP | CLAMP |
| 7. | 2418P9899D1 | [1] | PLATE | KOBPLATE |
| 8. | 2418P9899D2 | [1] | PLATE | KOB |
| 9. | 2418Z844 | [1] | RIGID TUBE | KOB |
| 10. | 2444Z2157 | [1] | SOCKET | KOB |
| 11. | R16P0036D3 | [2] | CLIP CLAMP | CLIP CLAMP |
| 12. | 2416Z302D5 | [2] | SHEET | KOB |
| 13. | 2444Z2158 | [1] | SOCKET | KOBSOCKET |
| 14. | 2420Z1006 | [1] | PLUG | PLUG |
| 15. | 2416T11060 | [1] | BRACKET | KOB |
| 17. | 2444Z1630 | [1] | FITTING | KOBConnector -- 3/8" PT Hose |
| 20. | 2444Z1633 | [1] | COCK | KOBCOCK Superseded by part number: PH21M01008P1 |
| 22. | 2444Z1632 | [1] | COCK JOINT | COCK JOINT |
| 24. | 2418T10455 | [2] | PIPE | KOB |
| 25. | R18T0026D11 | [2] | HOSE | HOSE |
| 30. | 2444Z2220D2 | [1] | HOSE | KOB |
| 31. | 2444Z2220D3 | [1] | HOSE | KOB |
| 32. | 2444Z2156D4 | [1] | HOSE | KOB |
| 33. | 2420Z699 | [1] | GROMMET | KOB |
| 34. | 2432Z290 | [5] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 35. | 2414Z199D25 | [1] | PROTECTIVE SLEEVE | KOB Superseded by part number: 2414Z199D025 |
| 36. | B16T0238D1 | [4] | CLAMP | |
| 37. | ZC15X02300 | [4] | CLIP | KOB |
| 38. | 2479Z913 | [1] | WIRE HARNESS | KOB |
| 39. | ZS16C10025 | [4] | SCREW | KOBM10x1.50x25mm Superseded by part number: ZS18C10025 |
| 40. | ZS16C12025 | [2] | CAPSCREW M12x1.75x25mm | CAPSCREW M12x1.75x25mm |
| 41. | ZS16C06020 | [2] | CAPSCREW | |
| 42. | ZM11C10025 | [1] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 43. | ZS16C08016 | [2] | SCREW | KOBM08x1.25x16mm Superseded by part number: ZS18C08016 |
| 44. | ZW26X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 45. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 46. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 47. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 48. | ZN11C12010 | [2] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 49. | ZN11C10008 | [4] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 50. | ZN11C08007 | [2] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 51. | ZN11C06005 | [2] | NUT | KOBNUT M06x1.0mm Superseded by part number: ZN18C06005 |
| 54. | R16P0036D9 | [2] | CLAMP | CLAMP |
| 59. | 2422P618D2 | [1] | PLATE, FLOOR | |
