神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (08-028) - LIGHT, BACK (FOR EXPORT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
154 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1039F1 | [1] | LIGHT, BACK LE3401, Serial Range: -LE4149 | |
| . . | 24100P1039F3 | [1] | LIGHT, BACK, Start Serial: LE4160- | |
| 1. | 2456R123D2 | [1] | LIGHT | KOB(12), Serial Range: LE3401-LE4149 Superseded by part number: 2456R123D3 |
| 2. | 2418T10535 | [1] | PLATE | |
| 4. | 2479Z849 | [1] | SWITCH | KOBTOGGLE Superseded by part number: 2479Z514 |
| 5. | 2479Z869D1 | [1] | HARNESS | |
| 6. | 2479Z851 | [1] | HARNESS | |
| 7. | ZM11C10030 | [1] | SCREW | KOBM10x1.50x30mm (Incls. Lockwasher) |
| 9. | 2432Z309D2 | [2] | CLAMP | KOB |
| 10. | 2432Z290D3 | [6] | CLIP | KOBWire Ties -- 154mm Long Superseded by part number: PY01P01043D3 |
| 12. | 2456R123D3 | [2] | LIGHT | KOBLIGHT ASSY, Start Serial: LE4150- |
