纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-59-00[02]) - INSTRUMENT PANEL ASSEMBLY (YT17M00024F1), PAGE 2 OF 3 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
652 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YN17M01344F2 | [1] | COVER ASSY | KOBIncls. Refs. A1-1 |
| A1-1. | YN17M01299F1 | [1] | COVER ASSY | KOBIncls. Refs. A1-1B & A1-1C |
| A1-1B. | YN17M01300P1 | [1] | DATA PLAQUE | SMDecal -- High/Low Position |
| A1-1C. | YN17M01312P1 | [1] | DATA PLAQUE | SMDecal -- Key Switch Position |
| A1-2. | YN52S00032P1 | [1] | POTENTIOMETER | KOBCab Fan Control Switch - High/Low, Includes Refs. A1-2A & A1-2B Superseded by part number: YN52S00032P2 |
| A1-2A. | YN52S00032S001 | [1] | POTENTIOMETER | KOBFan Control Switch Superseded by part number: YN52S00032P2 |
| A1-2B. | YN52S00032S002 | [1] | KNOB | KOBFan Control Switch Superseded by part number: YN52S00032S003 |
| A1-3. | YN17M01273P1 | [1] | BRACKET | SM |
| A1-5. | ZW16P05000 | [2] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| A1-6. | YN17M01262P1 | [2] | SCREW,Phillips Drive, Pan HD, M5 x 10mm | SMM05x10mm Self-Taper |
| A1-7. | ZM41C04012 | [2] | BOLT | KOBM04x0.7x12mm (Incls. Washer & Lockwasher) |
| A1-8. | YN17M01345P1 | [2] | WASHER | SMID 20.5 x OD 30 x Th 3.0mm |
| A1-9. | YN01E01018P1 | [1] | TERMINAL | SM |
| A1-10. | YN50S00026F2 | [1] | SWITCH | KOBAssembly, Key, Incls. Refs. A1-10A - A1-10E |
| A1-10A. | PM50S01001P1 | [1] | IGNITION KEY | KOBKEY, LOCK Key |
| A1-10B. | YN50S00002S002 | [1] | NUT | KOBAssembly |
| A1-10C. | YN50S00002S003 | [2] | WASHER | KOBPlain |
| A1-10D. | YN50S00002S004 | [1] | TOGGLE SWITCH | KOBKey |
| A1-10E. | YN50S00002S005 | [1] | WASHER | KOBWave |
| A2. | YB17M01015F2 | [1] | COVER ASSY | KOBIncls. Refs. A2-2 & A2-3 |
| A2-2. | YN81S00003P1 | [1] | CIGARETTE LIGHTER | SM |
| A2-3. | YB17M01023F2 | [1] | COVER ASSY | KOBIncls. Refs. A2-3E - A2-3G |
| A2-3E. | YN17M01293P1 | [2] | CLIP | KOB |
| A2-3F. | YN17M01303P1 | [2] | COLLAR | KOBCollar |
| A2-3G. | YN17M01296P1 | [1] | HOSE CLIP | SMCollar |
| A8. | YN17M01269P1 | [1] | BRACKET | SM |
| A9. | YN17M01270P1 | [1] | BRACKET | SM |
| A10. | YN17M01275P1 | [1] | BRACKET | SM |
| A11. | YB17M01011P1 | [1] | BRACKET | KOB |
| A12. | YN17M01267P1 | [2] | CAP | KOB |
| A15. | YN17M01283P1 | [1] | BOLT | SMM06x1.0x30mm (Incls. Washer & Lockwasher) |
| A16. | YN17M01284P2 | [2] | BOLT | SMM06x1.0x16mm (Incls. Washer & Lockwasher) |
| A20. | ZM66C06016 | [15] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| A23. | ZM41C05016 | [4] | BOLT | KOBM05x0.8x16mm (Incls. Washer & Lockwasher) |
| B1. | YN50S00040D1 | [1] | LIGHT SWITCH | SM(Work Light) |
| B2. | YN17M01282P1 | [4] | CAP | KOBPlug |
