神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (08-039) - WIRING ASSY, ELEC (FOR EXPORT) P/N 24100N2815F10 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
376 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2815F10 | [1] | WIRING ASSY, ELEC | |
| 9. | 2479U311 | [1] | HARNESS | KOB |
| 15. | 2479U253D2 | [1] | RADIO | KOB |
| 16. | 2416P2954 | [1] | BRACKET | BRACKET |
| 19. | 2479U244 | [1] | SPEAKER | KOB |
| 20. | ZS32T40025 | [4] | SCREW, TAPPING M04x25mm Self-Taper | SCREW, TAPPING M04x25mm Self-Taper |
| 21. | 2416T12835 | [1] | BRACKET | BRACKET |
| 22. | ZM11C08016 | [2] | BOLT | KOBM08x1.25x16mm (Incls. Lockwasher) |
| 23. | 2427Z511 | [1] | ASH TRAY | KOB |
| 24. | ZS41C04008 | [2] | CAPSCREW,M4 x 8mm | KOBSCREW M04x0.7x08mm |
| 26. | 2479R692 | [1] | WIRE HARNESS | KOB |
| 27. | 2479Z926 | [1] | HARNESS | KOB |
| 28. | R79T0058 | [1] | SWITCH | KOB |
| 29. | 2479Z928 | [1] | WIRE HARNESS | KOB |
| 30. | 2416T12947 | [1] | SUPPORT | |
| 31. | ZS11C06014 | [2] | SCREW,Hex, M6 x 14mm, Cl 4.8 | KOBM06x1.0x14mm Superseded by part number: ZS16C06014 |
| 32. | ZS31C06014 | [2] | SCREW,Phillips Drive, Pan HD, M6 x 14mm | KOBM06x1.0x14mm |
| 33. | ZN11C06005 | [2] | NUT | KOBNUT M06x1.0mm Superseded by part number: ZN18C06005 |
| 34. | ZW22X06000 | [4] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 35. | 2479Z844 | [1] | HARNESS | HARNESS |
