神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (05-003) - ROLLER ASSY (LOWER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
248 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2969F1 | [1] | TRACK ROLLER | KOB |
| 1. | 2413N385 | [1] | TRACK ROLLER | KOB |
| 2. | 2419P1531C2 | [1] | PIN | PIN |
| 3. | 2418N1894D1 | [1] | COLLAR | COLLAR |
| 4. | 2418N1894D2 | [1] | COLLAR | COLLAR |
| 5. | 2418T3578 | [4] | RING | RING |
| 6. | 2445Z1111 | [2] | SEAL,FLOATING | SEAL,FLOATING |
| 7. | ZD11G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 8. | ZE82T04000 | [2] | PLUG | KOB1/4" PT |
| 9. | 2405P478 | [2] | BUSHING | KOB |
