神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (07-008) - ALARM, OVER LOAD, P/N 24100N4014F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
545 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4014F2 | [1] | ALARM, OVER LOAD | |
| 24. | ZF23G12004 | [1] | CONNECTOR | CONNECTOR |
| 30. | ZN18C06005 | [1] | NUT | KOBM06x1.0mm |
| 31. | ZW26X06000 | [3] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 33. | ZF83H12000 | [1] | PLUG | KOB |
| 34. | 24044Z71F3 | [1] | KIT,TUBE LINE | |
| 34-2. | 2436R620F1 | [1] | VALVE PRESSURE RELIE | KOB |
| 34-4. | ZF23G12004 | [1] | CONNECTOR | CONNECTOR |
| 34-5. | ZF23E12004 | [1] | CONNECTOR | |
| 34-6. | ZF53B12000 | [1] | TEE | KOB |
| 34-7. | ZF83P12000 | [1] | PLUG | KOB |
| 34-8. | ZF93N12000 | [1] | NUT | KOB |
| 34-9. | ZX58N06080 | [1] | HOSE | |
| 34-10. | 2418T10349 | [2] | TUBE | |
| 34-11. | ZF33E12004 | [1] | ELBOW | |
| 35. | 2416T13292 | [1] | BRACKET | |
| 36. | 2479Z444 | [1] | BUZZER | |
| 37. | R79P0060F1 | [1] | LAMP | KOB |
| 38. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 39. | 2479Z985 | [1] | HARNESS | |
| 40. | 2420Z1042 | [1] | GROMMET | KOB Superseded by part number: 2420Z1301 |
| 41. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
