神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (11-012) - VALVE ASSY, P/N 2436R790F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
513 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R790F1 | [1] | VALVE ASSY | |
| . . | 2436R790F2 | [1] | VALVE ASSY | VALVE ASSY |
| . . | 2436R790F3 | [1] | VALVE | KOBASSY Superseded by part number: 2436R790F8 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONSHIM(F2 ONLY) |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONSHIM(F3 ONLY) |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBODY(F1-F3 ONLY) |
| 161. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm, (F1-F3 Only) |
| 162. | 2436U625S156 | [1] | PLUG | KOBF1-F3 ONLY) |
| 163. | ZD85P02000 | [1] | RING | KOBBack-Up -- ID 20 x OD 24 x Th 1.25mm, (F1-F3 Only) |
| 251. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG(F1-F3 ONLY) |
| 261. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm, (F1-F5 Only) |
| 311. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER(F1-F3 ONLY) |
| 312. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON(F1-F3 ONLY) |
| 313. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT(F1-F3 ONLY) |
| 315. | NSS | [1] | NOT SOLD SEPARAT | CONBALL(F1-F3 ONLY) |
| 321. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING(F1-F3 ONLY) |
| 322. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING(F1-F3 ONLY) |
| 371. | NSS | [1] | NOT SOLD SEPARAT | CONSHIM(F1 ONLY) |
