现代零件查询R36N-7 TRAVEL MOTOREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
882 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01995
|
[1] |
TRAVEL MOTOR
|
|
| 101. |
XJDH-03376
|
[1] |
SEAL KIT
|
|
| 102. |
XJDH-03383
|
[1] |
O-RING
|
|
| 103. |
XJDH-03378
|
[2] |
O-RING
|
|
| 104. |
XJDH-03384
|
[1] |
O-RING
|
|
| 105. |
XJDH-03380
|
[2] |
SEAL-FLOATING
|
|
| 106. |
XJDH-00331
|
[3] |
O-RING
|
|
| 107. |
XJDH-03381
|
[1] |
SEAL-OIL
|
|
| 108. |
XJDH-00335
|
[2] |
O-RING
|
|
| 109. |
XJDH-03345
|
[2] |
O-RING
|
|
| 110. |
XJDH-00328
|
[1] |
O-RING
|
|
| 2. |
XJDH-00072
|
[9] |
BOLT
|
|
| 3. |
XJDH-00280
|
[9] |
WASHER
|
|
| 4. |
XJDH-00457
|
[2] |
CONNECTOR-MALE
|
|
| 5. |
XJDH-00445
|
[2] |
CONNECTOR-MALE
|
|
