凯斯零件查询(LB424S XL) - BALER (11/16-) (35.560.010) - PICK-UP LIFTING SYSTEM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
947 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84818223
|
[1] |
HYDRAULIC CYLINDER,30mm Rod, 230mm Stroke
|
ZED
Incl 21
|
| 2. |
84332372
|
[1] |
TUBE
|
ZED
|
| 2. |
84534194
|
[1] |
TUBE
|
ZED
|
| 3. |
84335005
|
[1] |
GUIDE
|
ZED
|
| 3. |
84817374
|
[1] |
GUIDE
|
ZED
|
| 4. |
84817381
|
[1] |
BUSHING,51.3mm ID x 60.3mm OD x 20mm L
|
ZED
|
| 5. |
84817383
|
[1] |
BUSHING
|
ZED
|
| 6. |
9837602
|
[1] |
BUSHING,31mm ID x 40mm OD x 80mm L
|
ZED
|
| 7. |
84024657
|
[2] |
BUSHING
|
PLO
|
| 8. |
84367996
|
[1] |
SPRING
|
ZED
|
| 8. |
84817444
|
[1] |
SPRING
|
ZED
Superseded by part number: 84801205
|
| 9. |
395528
|
[1] |
BOLT,Hex, M20 x 2.5 x 100mm, Cl 8.8
|
NH
|
| 10. |
84021067
|
[1] |
PIN
|
ZED
|
| 11. |
380424
|
[1] |
NUT,M20 x 2.5, Cl 8
|
FOR
|
| 12. |
9838996
|
[1] |
COTTER PIN
|
NH
|
| 13. |
336793
|
[1] |
CLEVIS PIN,M10 x 55
|
ZED
Superseded by part number: 80336793
|
| 14. |
84045619
|
[1] |
PIN,12mm OD x 72.5mm L
|
ZED
|
| 15. |
9820493
|
[1] |
WASHER,20.5mm ID x 35mm OD x 2mm Thk
|
ZED
|
| 16. |
130011
|
[1] |
COTTER PIN,M5 x 40
|
ZED
|
| 17. |
84818191
|
[1] |
SUPPORT
|
ZED
|
| 18. |
84807781
|
[2] |
WING NUT,M8
|
NH
|
| 19. |
378244
|
[1] |
WASHER,10.5mm ID x 24mm OD x 2mm Thk
|
NH
|
| 20. |
130003
|
[1] |
COTTER PIN,3mm OD x 30mm OAL
|
ZED
|
| 21. |
84045272
|
[1] |
SEAL KIT
|
ZED
|
| 22. |
370539
|
[1] |
COTTER PIN,4.4mm x 52.8mm L
|
ZED
|
