神钢零件查询(K905A) - EXCAVATOR ASN LP1601 (1/83-12/03) (08-019) - PARTS KIT (AIR CONDITIONER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
439 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100U347F1 | [1] | PARTS KIT(AIR CONDITIONER) | |
| 1. | 24100U346S1 | [1] | HOSE, SUCTION | HOSE, SUCTION |
| 2. | 24100U347S2 | [1] | HOSE | |
| 3. | 24100U347S3 | [1] | HOSE | |
| 4. | 24100U347S4 | [1] | HOSE | |
| 5. | 24100U347S5 | [1] | TANK | |
| 6. | 24100U347S6 | [1] | PULLEY | KOB |
| 7. | 24100U347S7 | [1] | BELT | |
| 8. | 24100U346S9 | [1] | CLAMP | |
| 9. | 24100U346S10 | [1] | CLAMP | |
| 10. | 24100U346S20 | [1] | CLAMP | |
| 11. | 24100U346S12 | [1] | CLAMP | |
| 12. | 24100U346S13 | [3] | INSULATOR | |
| 13. | 24100U346S14 | [2] | INSULATOR | |
| 14. | 24100U346S19 | [2] | BUSHING | |
| 15. | 24100U346S15 | [10] | CLIP | |
| 16. | 24100U346S16 | [2] | BAND | |
| 17. | 24100U346S18 | [2] | PACKING | |
