凯斯零件查询(LB424S XL) - BALER (11/16-) (55.511.060) - SIDE LIGHTS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
856 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
48017456
|
[2] |
WIRE HARNESS
|
ZED
|
| 2. |
84554130
|
[1] |
WIRE HARNESS
|
ZED
|
| 3. |
48016166
|
[2] |
PLATE
|
ZED
|
| 4. |
47381350
|
[2] |
POSITION LAMP
|
PLO
|
| 5. |
353078
|
[2] |
BULB,T8/4, 12V, 4W
|
ZED
Superseded by part number: 3050199R91
|
| 6. |
86566990
|
[33] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 7. |
86511042
|
[4] |
SCREW,Pan Head, M4 x 0.7 x 16mm, Cl 4.8
|
ZED
Superseded by part number: 13272214
|
| 8. |
120039
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 54.8mm, Cl 8.8
|
WIN
|
| 9. |
322355
|
[4] |
BELLEVILLE WASHER,M4 Bolt Size x 10mm OD x 0.9mm Thk
|
NH
|
| 10. |
86639313
|
[4] |
WASHER,9mm ID x 24mm OD x 2mm Thk
|
RAC
|
| 11. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 12. |
385681
|
[4] |
NUT,M4 x 0.7, Cl 8
|
MKT
|
| 13. |
87301462
|
[4] |
CROWN NUT,Crown, M8, Cl6
|
ZED
|
