凯斯零件查询(LB424S XL) - BALER (11/16-) (60.280.080) - SHUTTLE FEEDER, CLUTCH, LH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
677 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84383755
|
[1] |
CRANK
|
ZED
|
| 2. |
84056050
|
[1] |
BALL BEARING,20mm ID x 52mm OD x 20.6mm W
|
ZED
|
| 3. |
370024
|
[1] |
CIRCLIP,M20, Ext
|
NH
|
| 4. |
673
|
[1] |
WASHER,29mm ID x 41mm OD x 1.52mm Thk
|
NH
|
| 5. |
84569894
|
[1] |
DOG
|
ZED
,, Serial Range: -C098 Superseded by part number: 47675729, 321204, 47517755
|
| 5. |
47675729
|
[1] |
DOG
|
ZED
,, Start Serial: D099
|
| 6. |
84465218
|
[1] |
SPINDLE
|
ZED
|
| 7. |
84400783
|
[1] |
ROLLER
|
ZED
|
| 8. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 9. |
84264111
|
[1] |
SHAFT
|
ZED
,, Serial Range: -C098 Superseded by part number: 321204, 47517755
|
| 9. |
47517755
|
[1] |
SHAFT
|
ZED
,, Start Serial: D099
|
| 10. |
301644
|
[1] |
CIRCLIP,M30, Int
|
COE
|
| 11. |
84806601
|
[1] |
SPRING,Extension, 28.399mm OD x 108mm L
|
ZED
,, Serial Range: -C055
|
| 11. |
47418582
|
[1] |
SPRING
|
ZED
,, Start Serial: D056
|
| 12. |
11057876
|
[1] |
SNAP RING,M20, Int
|
LEC
|
