| 1. |
84465213
|
[1] |
CLUTCH
|
ZED
Incl 2 - 10, Serial Range: -C098 Superseded by part number: 47471156
|
| 1. |
47471156
|
[1] |
CLUTCH
|
ZED
, Start Serial: D099
|
| 2. |
84242571
|
[1] |
ARM
|
ZED
, Serial Range: -C098 Superseded by part number: 370002, 47462229, 47442560, 47427605, 321204
|
| 2. |
47442560
|
[1] |
ARM
|
ZED
, Start Serial: D099
|
| 3. |
84465260
|
[1] |
SPINDLE
|
ZED
, Serial Range: -C084 Superseded by part number: 47462229, 321204, 47427605, 370002, 47442560
|
| 3. |
47497715
|
[1] |
ARM
|
ZED
, Serial Range: -F085098 Superseded by part number: 47462229, 47442560, 47427605, 370002, 321204
|
| 3. |
47462229
|
[1] |
ARM
|
ZED
, Start Serial: D099
|
| 4. |
84400783
|
[1] |
ROLLER
|
ZED
|
| 5. |
84465218
|
[1] |
SPINDLE
|
ZED
|
| 6. |
11057876
|
[1] |
SNAP RING,M20, Int
|
LEC
|
| 7. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 8. |
84806601
|
[1] |
SPRING,Extension, 28.399mm OD x 108mm L
|
ZED
, Serial Range: -C047
|
| 8. |
47418582
|
[1] |
SPRING
|
ZED
, Start Serial: D048
|
| 9. |
84242576
|
[1] |
SPINDLE
|
ZED
, Serial Range: -C047 Superseded by part number: 47462229, 47442560, 47427605, 321204, 370002
|
| 9. |
47442642
|
[1] |
SPINDLE
|
ZED
, Serial Range: -F048084 Superseded by part number: 47462229, 47427605, 47442560, 370002, 321204
|
| 9. |
47475426
|
[1] |
SPINDLE,39.73mm OD x 123.3mm L
|
ZED
, Serial Range: -F085098 Superseded by part number: 370002, 47427605, 321204, 47442560, 47462229
|
| 9. |
47427605
|
[1] |
SPINDLE
|
ZED
, Start Serial: D099
|
| 10. |
301644
|
[1] |
CIRCLIP,M30, Int
|
COE
, Serial Range: -C098
|
| 10. |
370002
|
[1] |
CIRCLIP,M25, External
|
NH
, Start Serial: D099
|
| 11. |
9838753
|
[2] |
KEY
|
ZED
|
| 12. |
9838835
|
[10] |
SHIM,57.15mm ID x 76.2mm OD x 0.25mm Thk
|
ZED
|
| 13. |
9838834
|
[7] |
SHIM,57.15mm ID x 76.2mm OD x 0.8mm Thk
|
ZED
|
| 14. |
327911
|
[3] |
CIRCLIP,55mm ID
|
BHB
|
| 15. |
84814919
|
[1] |
SET SCREW,M12 x 20mm, Cl 8.8
|
ZED
, Serial Range: -C144
|
| 15. |
300388
|
[1] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8
|
NH
, Start Serial: D145
|
| 16. |
853175
|
[2] |
FLANGE
|
ZED
Superseded by part number: 76450
|
| 17. |
9839285
|
[1] |
BALL BEARING,55mm ID x 100mm OD x 24mm W
|
ZED
|
| 18. |
9837743
|
[5] |
KIT,56mm ID x 70.3mm OD x 2mm Thk
|
ZED
|
| 19. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 20. |
84338715
|
[1] |
BELLCRANK
|
ZED
, Serial Range: -C098 Superseded by part number: 47612327
|
| 20. |
47612327
|
[1] |
BELLCRANK
|
ZED
, Start Serial: D099
|
| 21. |
87665470
|
[1] |
BRAKE DISC
|
ZED
|
| 22. |
140045
|
[3] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 23. |
43140
|
[3] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 24. |
87660400
|
[2] |
BRAKE SHOE
|
ZED
|
| 25. |
320502
|
[3] |
SPRING
|
ZED
|
| 26. |
87661858
|
[1] |
BRACKET, SUPPORTING
|
ZED
|
| 27. |
300381
|
[1] |
BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8
|
NH
Superseded by part number: 412479, 412479, 614-8035
|
| 28. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 29. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 30. |
87663943
|
[2] |
CARRIAGE BOLT,Sq Nk, M10 x 1.5 x 75mm, Cl 8.8
|
ZED
|
| 31. |
84005615
|
[2] |
WASHER,10.5mm ID x 32mm OD x 2mm Thk
|
ZED
|
| 32. |
100037
|
[2] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 33. |
374895
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 34. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
