凯斯零件查询(LB424S XL) - BALER (11/16-) (68.120.020) - KNOTTER CLUTCH ARM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
898 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84542157
|
[1] |
ARM
|
ZED
|
| 2. |
84000033
|
[1] |
ARM
|
ZED
|
| 3. |
9838376
|
[1] |
ROLLER,50mm OD x 17mm L
|
ZED
|
| 4. |
370024
|
[1] |
CIRCLIP,M20, Ext
|
NH
|
| 5. |
84000011
|
[2] |
WASHER,30.5mm ID x 40mm OD x 1mm Thk
|
ZED
|
| 6. |
673
|
[2] |
WASHER,29mm ID x 41mm OD x 1.52mm Thk
|
NH
|
| 7. |
300629
|
[1] |
SNAP RING,M28, Ext
|
ZED
|
| 8. |
86512446
|
[2] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 9. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 10. |
100037
|
[2] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
