凯斯零件查询(LB424S XL) - BALER (11/16-) (68.120.030) - BALE LENGTH ADJUSTMENT, IDLER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
969 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84817360
|
[1] |
SUPPORT
|
ZED
|
| 2. |
120044
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 3. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 4. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 5. |
84057311
|
[2] |
BUSHING,25mm ID x 28mm OD x 20mm L
|
ZED
|
| 6. |
84817387
|
[1] |
SHAFT
|
ZED
|
| 7. |
431485
|
[2] |
UNIVERSAL JOINT
|
ZED
|
| 8. |
34439
|
[2] |
BALL BEARING,25 mm ID x 52 mm OD x 15 mm
|
NNA
Superseded by part number: 443898
|
| 9. |
338206
|
[1] |
WASHER,26mm ID x 35mm OD x 2mm Thk
|
ZED
|
| 10. |
84488484
|
[1] |
PLOW DISC
|
ZED
, Serial Range: -C098
|
| 10. |
47644922
|
[1] |
PLOW DISC
|
ZED
, Start Serial: D099
|
| 11. |
84817692
|
[1] |
TUBE
|
ZED
|
| 11. |
84817391
|
[1] |
TUBE
|
ZED
|
| 12. |
84533795
|
[1] |
SUPPORT
|
ZED
|
| 13. |
86624184
|
[8] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 14. |
43128
|
[8] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 15. |
322358
|
[12] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 16. |
9706690
|
[12] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 17. |
84031601
|
[1] |
SHIELD
|
ZED
|
| 18. |
120104
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 19. |
87730773
|
[1] |
CAP
|
ZED
|
| 20. |
385188
|
[3] |
SHIM,26mm ID x 34mm OD x 0.5mm Thk
|
PA
|
| 21. |
9839230
|
[1] |
WASHER
|
ZED
Superseded by part number: 27317
|
| 22. |
370002
|
[1] |
CIRCLIP,M25, External
|
NH
|
| 23. |
9511052
|
[2] |
WASHER,13.5mm ID x 44mm OD x 4mm Thk
|
NH
|
| 24. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 25. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 26. |
86633356
|
[2] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
, Serial Range: -C098
|
| 26. |
86512446
|
[2] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
, Start Serial: D099
|
| 27. |
84475774
|
[4] |
SHIM
|
ZED
|
