凯斯零件查询(LB424S XL) - BALER (11/16-) (88.055.034) - DIA KIT: TWINE BOX LIGHTING KIT - LED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
911 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47968871
|
[1] |
DIA KIT, HARVESTER
|
COE
Incl 2 - 12
|
| 2. |
47966366
|
[1] |
WIRE HARNESS
|
ZED
|
| 4. |
47506757
|
[1] |
COURTESY LIGHT
|
ZED
|
| 6. |
47533109
|
[4] |
SUPPORT
|
ZED
|
| 7. |
87530614
|
[4] |
GROMMET
|
WIC
|
| 8. |
86566990
|
[12] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 9. |
84322203
|
[2] |
CLIP
|
BUR
|
| 10. |
9507807
|
[8] |
CLAMP,8.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 11. |
84280063
|
[4] |
HALF-HINGE
|
ZED
|
| 12. |
445394
|
[16] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
