神钢零件查询(K909LC) - MARK II EXCAVATOR BTW LL1207 - LL1487 (1/87-12/03) (01-001) - FRAME ASSY, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
642 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6594F3 | [1] | FRAME ASSY,UPP | |
| 2. | 2414T2341 | [1] | COVER | KOB Superseded by part number: YN52F01158P1 |
| 3. | 2414Z234 | [1] | COVER | KOB |
| 4. | 2418T12125 | [1] | PLATE | KOB Superseded by part number: YN52F01159P1 |
| 5. | 2416Z434 | [1] | PACKING | KOBRubber |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONMOTOR ASSV,SWING (P.025-01) |
| 7. | 2420R561D1 | [1] | DIPSTICK | KOB |
| 8. | 2420T4039C2D7 | [1] | RIGID TUBE | KOB |
| 9. | 24100P1564F1 | [1] | BOX ASSY, TOOL | BOX ASSY, TOOL |
| 9-1. | 2427P2492 | [1] | CAM BOX,TOOL | CAM BOX,TOOL |
| 9-2. | 2414P4756 | [1] | COVER | COVER |
| 9-3. | 2432Z451 | [1] | CATCH | KOB |
| 9-4. | ZS16C08016 | [4] | SCREW | KOBM08x1.25x16mm Superseded by part number: ZS18C08016 |
| 9-5. | ZS31C03008 | [2] | SCREW,Phillips Drive, Pan HD, M3 x 8mm | KOBM03x0.5x08mm |
| 9-6. | ZN16C08007 | [4] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 9-7. | ZN11C03003 | [2] | NUT | KOBM03x0.5mm |
| 9-8. | ZW22X08000 | [4] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 9-9. | ZW26X03000 | [2] | LOCK WASHER | HIT |
| 10. | ZS13C10025 | [8] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 11. | ZS23C20065 | [16] | SCREW,Hex Socket Head, M20 x 65mm | KOBM20x2.5x65mm |
| 12. | ZS18C12020 | [2] | SCREW,Hex, M12 x 20mm | KOBM12x1.75x20mm |
| 13. | ZS13C20120 | [30] | SCREW | KOBM20x2.50x120mm |
| 14. | 2420Z1201 | [3] | SCREW | KOBCAP |
| 15. | 2418T5373C2 | [8] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 16. | ZW26X12000 | [20] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm, Serial Range: LL1207-LL1287 |
| 17. | 2418T10357 | [20] | WASHER | KOBID 13 x OD 30 x Th 3.2mm, Serial Range: LL1207-LL1287 Superseded by part number: 2418T12345 |
| 18. | ZW13H20000 | [33] | WASHER | KOBID 20 x OD 40 x Th 4.5mm |
| 19. | 2456Z253 | [1] | MIRROR | KOB |
| 20. | 2406P2568 | [1] | STAY | KOB |
| 26. | 24100P1767F1 | [2] | PROTECTOR | KOB |
| 26-1. | 2427J1322 | [1] | PROTECTOR | KOBPROTECTOR |
| 26-2. | 2427T1836 | [1] | FOAM INSULATION | KOB |
| 27. | 2427N1672D1 | [1] | PROTECTOR | KOB |
| 28. | 2427N1672D2 | [1] | PROTECTOR | KOB |
| 29. | ZS18C12030 | [18] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm, Serial Range: LLI207-LL1287 |
| 32. | 2422J1973 | [1] | FRAME,UPP | |
| 32-1. | 2405T1260 | [2] | BUSHING | KOB |
| 32-2. | 2414T2795 | [1] | COVER | KOB |
| 32-3. | ZS83C20020 | [2] | SCREW | KOBSet -- M20x2.50x20mm |
