纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-046) - GUARD INSTAL (BRACKET ASSY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
203 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY21C00010F2 | [1] | GUARD ASSY. | KOBINSTAL |
| . . | YY21C00010F5 | [1] | GUARD ASSY. | KOBINSTAL |
| . . | YY21C00010F6 | [1] | GUARD ASSY. | KOBINSTAL (FOR L) |
| 6. | YY21C01144F1 | [1] | COVER ASSY | KOB(FOR F5 ONLY) |
| 6-1. | YY21C01145P1 | [1] | COVER | KOB |
| 6-2. | YX21C01195P1 | [1] | INDICATOR | KOB |
| 17. | YY21C01123F2 | [1] | GUARD ASSY. | KOBASSY (FOR F2 ONLY) |
| 17-2. | YT21C01163DA | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| 17-3. | YV21C01099P1 | [1] | RUBBER | KOB |
| 17-4. | YT21C01037D6 | [1] | TRIM PANEL | KOB |
| 17-6. | LE21C01070DQ | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| 17-7. | YY21C01136P1 | [1] | GUARD | KOB |
| 17-8. | YR21C01168DH | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| 24. | YY21C01252F1 | [1] | GUARD ASSY. | KOB(FOR F2 ONLY) |
| 24-1. | YY21C01250P1 | [1] | GUARD | KOB |
| 24-1A. | PE22C01015P1 | [1] | HINGE | |
| 24-1B. | PM21C01221P1 | [1] | LOCK | KOB |
| 24-2. | PM21C01255P2 | [1] | GROMMET | KOB |
| 24-3. | PN02C01004D7 | [1] | TRIM PANEL | KOBSTRIP, WEATHER |
| 24-4. | PN02C01004D6 | [1] | SEAL PROTECTION | KOBSTRIP, WEATHER Superseded by part number: S16539-16000 |
| 41. | ZM32C12025 | [8] | BOLT | KOBSEMS (FOR F2 ONLY) |
| 42. | ZM32C12030 | [1] | BOLT | KOBSEMS (FOR F5, F6 ONLY) |
| 43. | ZS18C12045 | [3] | SCREW,Hex, M12 x 45mm | KOBCAP (FOR F5, F6 ONLY) |
| 48. | 2418T10357 | [3] | WASHER | KOB(FOR F5, F6 ONLY) Superseded by part number: 2418T12345 |
| 52. | ZW26X12000 | [3] | WASHER | KOB(For F5, F6 Only) |
| 117. | YY21C01144F2 | [1] | COVER ASSY | KOB(FOR F6 ONLY) |
| 117-3. | YY21C01253P1 | [1] | COVER | KOB |
