纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-047) - BONNET ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
115 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY22C00004F6 | [1] | GUARD | KOBBONNET ASSY |
| 2. | YY22C01006P1 | [1] | INDICATOR | KOB |
| 3. | YT21C01163DD | [2] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| 4. | YY22C01007P1 | [1] | INDICATOR | KOB |
| 5. | YY22C01008P1 | [1] | INDICATOR | KOB |
| 6. | 2420R603D4 | [1] | RUBBER | KOB |
| 7. | 2420Z1386 | [2] | GROMMET | KOB |
| 13. | YY22C01062P1 | [1] | GUARD | KOBBONNET ASSY |
| 14. | YX22C01011D2 | [1] | INSULATING PANEL | KOB |
| 15. | YY22C01055P1 | [2] | INSULATING PANEL | KOB |
| 17. | YY22C01056P1 | [1] | INSULATING PANEL | KOB |
| 18. | YY22C01053P1 | [1] | INSULATING PANEL | KOB |
| 19. | YT21C01163DC | [1] | WEATHERSTRIP | KOB |
| 20. | YW21C01057DB | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 40. | YY21C01721P1 | [1] | RUBBER, Start Serial: YV04-03086 | |
