纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-009) - CLEANER ASSY, AIR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
861 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW11P00012F1 | [1] | Cleaner Assembly, Air | |
| 1. | PW11P00015F1 | [1] | AIR CLEANER | KOBAssembly |
| 1-1. | PW11P00014S001 | [1] | BODY | KOBAssembly |
| 1-2. | PW11P00009S002 | [1] | COVER ASSY | KOB |
| 1-4. | PW11P00010S004 | [1] | INDICATOR | KOB |
| 1-5. | PW11P00012S005 | [1] | AIR FILTER | KOBElement Superseded by part number: 84221831 |
| 2. | PW11P01037P1 | [1] | HOSE | KOBAir |
| 3. | PW11P01031P1 | [1] | HOSE | KOBAir |
| 4. | PW11P01034P2 | [1] | BRACKET | KOB |
| 5. | ZC16X05800 | [3] | CLIP | KOBClamp, Hose -- Min 50 x Max 66mm |
| 6. | ZC16X04200 | [1] | CLAMP | KOBHose -- Min 32 x Max 51mm |
| 7. | ZM22C08020 | [2] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| 8. | ZM12C08025 | [2] | BOLT | KOBM08x1.25x25mm (Incls. Lockwasher) |
| 10. | NSS | [1] | NOT SERVICED SEPARATELY | CONIndicator |
| 12. | HX11Y03020DY | [1] | HOSE,12.7mm ID x 200mm L | KOBID 05 x OD 07 x 200mm Long (7-7/8 in) |
| 14. | ZM22C08016 | [2] | BOLT | KOBM08x1.25x16mm (Incls. Washer & Lockwasher) |
| 15. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
