纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-020) - HYD LINES, PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
455 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW30H00007F1 | [1] | HYD LINES, PUMP | |
| 1. | HH35S08008G1 | [3] | 90 ELBOW | KOB |
| 3. | 2444Z3715 | [1] | ELBOW | KOB |
| 4. | PW30H01058P1 | [1] | TEE | KOB |
| 5. | PA32H01017P1 | [1] | TEE | KOB Superseded by part number: 72956775 |
| 6. | PW30H01012P1 | [1] | TEE | KOB |
| 7. | ZE72X04000 | [3] | PLUG | KOB |
| 8. | PW30H01078P1 | [1] | HOSE,12.7mm ID x 1600mm L | KOB |
| 9. | PW30H01079P1 | [1] | HOSE,12.7mm ID x 1450mm L | KOB |
| 10. | PW30H01083P1 | [1] | HOSE,12.7mm ID x 1600mm L | KOB |
| 11. | PW30H01072P1 | [1] | HOSE | KOB |
| 12. | PW30H01063P1 | [1] | HOSE | KOB |
| 13. | PW30H01074P1 | [1] | TUBE | KOB |
| 14. | PW30H01067P1 | [1] | TUBE | KOB |
| 16. | PW30H01081P1 | [1] | BRACKET | KOB |
| 17. | PW30H01077P1 | [1] | GROMMET | KOB |
| 18. | ZD11G05000 | [1] | O-RING,3.1mm Thk x 49.4mm ID, 70 Duro | KOBO-RING |
| 19. | ZS28C12035 | [4] | CAPSCREW,Hex Socket Head, M12 x 35mm | KOBSCREW CAP |
| 20. | ZS18C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBCAP |
| 21. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 22. | ZW26K12000 | [4] | LOCK WASHER | KOB |
| 23. | ZW16H12000 | [2] | WASHER | KOB |
| 24. | ZW16H08000 | [1] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 25. | ZC16X05000 | [8] | CLIP | KOB |
| 26. | PM21C01152DL | [1] | WEATHERSTRIP | KOB |
| 30. | PW30H01071P1 | [1] | GUIDE | KOB |
